10KV-15KV
型号
Type |
额定电压
Rated
voltage
(KV) |
额定电流
Rated
Current
(A) |
开断电流
Breaking
Current
(A) |
冲出电压
Impulse
voltage
(BIL) |
工作耐压
Power-
frequency
withstand
voltage |
爬距
Leakage
distance
(MM) |
重量
Weight
(KG) |
外型尺寸
Dimensions
(CM) |
| RW3 |
10 |
100 |
6300 |
100 |
42 |
230 |
6.2 |
48x27
x12 |
| RW3 |
10 |
200 |
8000 |
100 |
42 |
230 |
6.2 | |
 |
10KV-15KV
型号
Type |
额定电压
Rated
voltage
(KV) |
额定电流
Rated
Current
(A) |
开断电流
Breaking
Current
(A) |
冲出电压
Impulse
voltage
(BIL) |
工作耐压
Power-
frequency
withstand
voltage |
爬距
Leakage
distance
(MM) |
重量
Weight
(KG) |
外型尺寸
Dimensions
(CM) |
| RW10-10F |
12 |
100 |
6300 |
110 |
42 |
260 |
7.5 |
53x32
x12 |
| RW10-10F |
12 |
200 |
8000 |
110 |
42 |
260 |
7.5 | |
 |
10KV-15KV
型号
Type |
额定电压
Rated
voltage
(KV) |
额定电流
Rated
Current
(A) |
开断电流
Breaking
Current
(A) |
冲出电压
Impulse
voltage
(BIL) |
工作耐压
Power-
frequency
withstand
voltage |
爬距
Leakage
distance
(MM) |
重量
Weight
(KG) |
外型尺寸
Dimensions
(CM) |
| RW7 |
10 |
100 |
6300 |
110 |
42 |
230 |
6.2 |
48x27
x12 |
| RW7 |
10 |
200 |
8000 |
110 |
42 |
230 |
6.2 | |
 |
10KV-15KV
型号
Type |
额定电压
Rated
voltage
(KV) |
额定电流
Rated
Current
(A) |
开断电流
Breaking
Current
(A) |
冲出电压
Impulse
voltage
(BIL) |
工作耐压
Power-
frequency
withstand
voltage |
爬距
Leakage
distance
(MM) |
重量
Weight
(KG) |
外型尺寸
Dimensions
(CM) |
| RW11 |
12 |
100 |
6300 |
110 |
42 |
260 |
7.5 |
53x32
x12 |
| RW11 |
12 |
200 |
8000 |
110 |
42 |
260 |
7.5 | |
 |
