双线管形顶绝缘端头
|
| 最大耐压：105℃ Ui=300V 材质：紫铜管 绝缘材质：尼龙 |
| 型号 |
编号 |
尺寸 |
导线截面 |
绝缘套颜色
(1)德国用
(2)法国用 |
| F |
L |
W |
DΦ |
CΦ |
A.W.G |
| E0506 |
18578 |
6.0 |
12.0 |
2.6 |
1.3 |
1.0 |
#22 |
0.5 |
(1)橙色
(2)白色 |
| E0508 |
18579 |
8.0 |
14.0 |
| E0510 |
18580 |
10.0 |
16.0 |
| E0512 |
18581 |
12.0 |
18.0 |
| E7506 |
18582 |
6.0 |
12.4 |
2.8 |
1.5 |
1.2 |
#20 |
0.75 |
(1)白色
(2)蓝色 |
| E7508 |
18583 |
8.0 |
14.6 |
| E7510 |
18584 |
10.0 |
16.4 |
| E7512 |
18585 |
12.0 |
18.4 |
| E1006 |
18586 |
6.0 |
12.4 |
3.0 |
1.7 |
1.4 |
#18 |
1.0 |
(1)黄色
(2)红色 |
| E1008 |
18587 |
8.0 |
14.6 |
| E1010 |
18588 |
10.0 |
16.4 |
| E1012 |
18589 |
12.0 |
18.4 |
| E1508 |
18590 |
8.0 |
14.6 |
3.5 |
2.0 |
1.7 |
#16 |
1.5 |
(1)红色
(2)黑色 |
| E1510 |
18591 |
10.0 |
16.4 |
| E1512 |
18592 |
12.0 |
18.4 |
| E1518 |
18593 |
18.0 |
24.4 |
| E2508 |
18594 |
8.0 |
15.2 |
4.0 |
2.6 |
2.3 |
#14 |
2.5 |
(1)蓝色
(2)灰色 |
| E2510 |
18595 |
10.0 |
17.2 |
| E2512 |
18596 |
12.0 |
19.2 |
| E2518 |
18597 |
18.0 |
25.2 |
| E4009 |
18598 |
9.0 |
16.5 |
4.4 |
3.2 |
2.8 |
#12 |
4.0 |
(1)灰色
(2)橙色 |
| E4012 |
18599 |
12.0 |
19.5 |
| E4018 |
18600 |
18.0 |
25.5 |
| E6010 |
18601 |
10.0 |
18.0 |
6.3 |
3.9 |
3.5 |
#10 |
6.0 |
(1)墨色
(2)绿色 |
| E4012 |
18602 |
12.0 |
20.0 |
| E4018 |
18603 |
18.0 |
26.0 |
| E10-12 |
18604 |
12.0 |
21.5 |
7.6 |
4.9 |
4.5 |
#7 |
10.0 |
(1)乳白色
(2)褐(棕)色 |
| E10-18 |
18605 |
18.0 |
25.5 |
| E16-12 |
18606 |
12.0 |
22.2 |
8.8 |
6.5 |
5.8 |
#5 |
16.0 |
(1)绿色
(2)乳白色 |
| E16-18 |
18607 |
18.0 |
28.2 |
| E25-16 |
18608 |
16.0 |
29.0 |
11.2 |
7.9 |
7.5 |
#4 |
25.0 |
(1)褐(棕)色
(2)黑色 |
| E25-22 |
18609 |
22.0 |
35.0 |
| E35-16 |
18610 |
16.0 |
30.0 |
12.7 |
8.7 |
8.3 |
#2 |
35.0 |
灰褐色 |
| E35-25 |
18611 |
25.0 |
39.0 |
| E50-20 |
18612 |
20.0 |
36.0 |
15.3 |
10.9 |
10.3 |
#1 |
50.0 |
橄榄色 |
| E50-25 |
18613 |
25.0 |
41.0 | | |
